| Management features |
| L2 |
Switch layer |
| Yes |
Quality of Service (QoS) support |
| Yes |
Multicast support |
| Yes |
ARP inspection |
| Ports & interfaces |
| 10 |
Basic switching RJ-45 Ethernet ports quantity |
| Fast Ethernet (10/100) |
Basic switching RJ-45 Ethernet ports type |
| 1000BASE-T,100BASE-TX,10BASE-T |
Copper ethernet cabling technology |
| 8 |
Fast Ethernet (copper) ports quantity |
| 2 |
Gigabit Ethernet (copper) ports quantity |
| Yes |
DC-in jack |
| Networking |
| IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3ah,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
Networking standards |
| Yes |
Full duplex |
| Yes |
Broadcast storm control |
| Yes |
VLAN support |
| Yes |
IP routing |
| No |
10G support |
| Yes |
DHCP server |
| Yes |
Private VLAN |
| Yes |
Protocol-based VLAN |
| Yes |
Spanning tree protocol |
| Yes |
IGMP snooping |
| Yes |
Link aggregation |
| Data transmission |
| 10 Gbit/s |
Switching capacity |
| 4.2 Mpps |
Throughput |
| 4000 entries |
MAC address table |
| 255 |
Number of VLANs |
| Yes |
Jumbo frames support |
| 9018 |
Jumbo frames |
| Security |
| Yes |
Access Control List (ACL) |
| Yes |
BPDU filtering/protection |
| 802.1x RADIUS,SSH |
Security algorithms |
| Yes |
SSH/SSL support |
| Protocols |
| SNMP |
Management protocols |
| Design |
| No |
Rack mounting |
| White |
Colour of product |
| Yes |
LED indicators |
| UL 60950-1, CAN/CSA 22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CE, GB 4943, IEC 60825 |
Safety |
| FCC, EN 55022 (CISPR22), EN 55024 (CISPR24), AS/NZS, VCCI, V-3/2007.04, KCC, ANATEL, CCC, GOST |
Electromagnetic compatibility |
| Performance |
| 128 MB |
Internal memory |
| 64 MB |
Flash memory |
| 471888 h |
Mean time between failures (MTBF) |
| Power |
| 15 W |
Power consumption (typical) |
| Power over Ethernet (PoE) |
| No |
Power over Ethernet (PoE) |
| Operational conditions |
| -5 - 45 °C |
Operating temperature (T-T) |
| 5 - 95 % |
Operating relative humidity (H-H) |
| 5 - 95 % |
Storage relative humidity (H-H) |
| 0 - 3048 m |
Operating altitude |
| 0 - 4000 m |
Non-operating altitude |
| Weight & dimensions |
| 269 mm |
Width |
| 172 mm |
Depth |
| 44.4 mm |
Height |
| 1080 g |
Weight |
